SCHWARZBECK 人工电源网络汇总

CISPR 16-1-2 socket

NSLK 8117

V-LISN

(50 µH + 5 Ω) || 50 Ω

2 x 10 A

2

NSLK 8127

V-LISN

(50 µH + 5 Ω) || 50 Ω

2 x 16 A

2

RC, PLC

NSLK 8126

V-LISN

(50 µH + 5 Ω) || 50 Ω

2 x 16 A Schuko

4 x 16 A CEKON

4

RC

NSLK 8128

V-LISN

(50 µH + 5 Ω) || 50 Ω

2 x 16 A Schuko and

4 x 32 A CEKON

4

RC

NSLK 8163

V-LISN

(50 µH + 5 Ω) || 50 Ω

4 x 64 A CEKON

4

RC

CISPR 16-1-2 Wing Terminals

NNLK 8121

V-LISN

(50 µH + 5 Ω) || 50 Ω

4 x 50 (100) A

4

RC, Hochstrom, 400/700V, Lüfter

NNLK 8122

V-LISN

(50 µH + 5 Ω) || 50 Ω

2 x 50 A

2

NNLK 8129

V-LISN

50 µH || 50 Ω

4 x 200 (300) A

4

RC, 400/700 V, Lüfter

NNLK 8129-2 HV

V-LISN

50 µH || 50 Ω

2 x 200 (300) A

2

RC,TC

NNLK 8130

V-LISN

50 µH || 50 Ω

4 x 400 (500) A

4

RC

NNLK 8140

V-LISN

50 µH || 50 Ω

1 x 800 (1000) A

single

Automotive

NNHV 8123

V-LISN

5µH || 50 Ω

70 (100) A

single

NNHV 8123-200

V-LISN

5µH || 50 Ω

200 A

single

NNHV 8123-400

V-LISN

5µH || 50 Ω

400 A

single

NNHV 8123-400R

V-LISN

(5µH + 1 Ω) || 50 Ω

400 A

single

NNHV 8123-800

V-LISN

5µH || 50 Ω

800 A

single

NNBM 8124

V-LISN

(5µH + 1 Ω) || 50 Ω

70 (100) A

single

N-connector

NNBM 8124-200

V-LISN

(5µH + 1 Ω) || 50 Ω

200 A

single

N-connector

NNBM 8124-400

V-LISN

(5µH + 1 Ω) || 50 Ω

400 A

single

N-connector

NNBM 8124-800

V-LISN

(5µH + 1 Ω) || 50 Ω

800 A

single

N-connector

NNBM 8126 A 890

V-LISN

5 µH || 50 Ω

70 (100) A

single

DO-160

NNBM DO160-1500

V-LISN

5 µH || 50 Ω

200 (280) A

single

BAN 8508

8 A (DC)

single

BAN 8530

30 A (DC)

single

MIL

NNBL 8225

V-LISN

(50 µH + 5 Ω) || 50 Ω

20 A

single

NNBL 8226

V-LISN

(50 µH + 5 Ω) || 50 Ω

70 (100) A

single

NNBL 8226-HV

V-LISN

(50 µH + 5 Ω) || 50 Ω

70 (100) A

single

NNBL 8226-2

V-LISN

(50 µH + 5 Ω) || 50 Ω

70 (100) A

2

NNBL 8229-HV

V-LISN

(50 µH + 5 Ω) || 50 Ω

200 A

single

NNBL 8230

V-LISN

(50 µH + 5 Ω) || 50 Ω

300 A

single

NNBL 8240

V-LISN

(50 µH + 5 Ω) || 50 Ω

800 (1000) A

single

T-ISN

NTFM 8131

T-ISN

150 Ω ± 10%

3 A (AC)

2

NTFM 8158

T-ISN

150 Ω ± 20 Ω

600 mA DC (pair)

2

CAT5 8158

T-ISN

150 Ω ± 20 Ω

600 mA DC (pair)

2

CAT3 8158

T-ISN

150 Ω ± 20 Ω

600 mA DC (pair)

2

ISN S8

T-ISN

150 Ω ±20 Ω
  150 Ω + 60 Ω /-45 Ω

1 A (DC)

8

ISN S1

T-ISN

150 Ω ±20 Ω
  150 Ω + 60 Ω /-45 Ω

1 A (DC)

single

Special - LISN

Pilot ISN

150 Ω ±20 Ω

1.4 A DC

2

ECSS LISN1

(1.5 µH) || 50 Ω

10 A

2

ECSS LISN 2

(2 µH) || 50 Ω

10 A

2

ECSS LISN 2 - 75A

(2 µH) || 50 Ω

75 A

2

ECSS LISN 3

(0.7 µH) || 50 Ω

10 A

2

NPLC 8500

V-LISN

1 Ω

16 A

single

PVDC 8300

PV-LISN
  Universal

150Ω common

100Ω differental

50 A (100 A with opt. fans)

2

Fans

PVDC 8301

PV-LISN
  Universal

150 Ω common
  100Ω differental

200 A

2

TEMP 8400

Tempest-

V-LISN

1.4 kΩ

16 A

2

TEMP 8401
